kide machine monoblock ESW2010M1G maintenance performance 1750W ceiling R-455A

Monoblock kide.Professional cooling equipment ,ceiling , for cold storage rooms, which have a small volume.

Series -200. Operating limits -5 Celcious until -10 Celcious

Model ESW2010M1G. Closed type compressor.

Cooling performance -1750W

For chamber volume 14-16m3 (in a hot climate – in a cold climate )

Power supply 230V/1/50HP

Compressor -11/4hp -0,9kW

Refrigerant – R-455A<0,96

Consumption 8.3A

Maximum load 10.2A

condenser -evaporator 2000m3

Weight -105 kilos

Pre-charged with coolant.
Water* or water + 30% ethylene glycol.
Power supply 230 V-I-50 Hz ή 400 5-3-50 Hz (ask about other trends).
Hermetic scroll compressor on anti-vibration mounts.
Liquid injection in low temperature models.
Condensation through a plate heat exchanger.
Fluid receiver.
Ceramic filter drier.
Liquid sight glass.
High and low pressure switches.
Service valves (series 200).
Pressure switch valve.
Hydraulic condensing circuit in copper pipe with screw connections.
Electric control panel with differential and magnetothermal protection.
Electric control panel with differential and magnetothermal protection.
Electronic regulation with remote control of the evaporator and the compressor, with temperature sensor.
Air exhaust fan.
Waterproof electrical panel.

OPTIONAL FOR kide MACHINES (Request delivery)

Winter Kit. Exchange system / failure for two units.
Synchronized defrost system for two units.
Voltage protector (single phase version).
Anti-corrosion treatment on the evaporator coil.
Time control.
Cubic evaporator for EEC3 models.
Humidifier external to the equipment and control (cooling).
Anti-corrosion treatment for condenser unit furniture.
Monitoring and control system

XWEB remote management.
