TCL CASSETTE TYPE AIR CONDITIONER 12.010 BTU TCD-12CHRH/DV
TCL CASSETTE TYPE AIR CONDITIONER 12.010 BTU TCD-12CHRH/DV
Why choose TCL Reliability and quality TCL Energy-efficient inverter operation Uniform air distribution Ideal for business premises The TCL cassette air conditioner combines technology, performance and comfort, being a top choice in its class. High performance and reliability TCL,TCL intelligent air distribution With adjustable louvers from 0° to 85°, the TCL system offers excellent airflow control and quiet TCL operation.
| BTU/H | |
|---|---|
| Manufacturers |
Description
TCL CASSETTE TYPE AIR CONDITIONER 12.010 BTU TCD-12CHRH/DV
Αποδοτική λύση για κάθε χώρο .Το TCL cassette air conditioner 12010 BTU it is a reliable choice for commercial and residential spaces that require consistent performance and comfort. Thanks to inverter technology, achieves low energy consumption and maintains a constant temperature, ensuring ideal conditions throughout operation. Even air flow and comfort. The adjustable louvers with an angle from 0° to 85° allow the ideal direction of the air, while the operation 8 directions ensures full coverage of the space. The system offers even distribution, in order to avoid points with different temperatures and to achieve the desired result immediately. Αθόρυβη λειτουργία και υγιεινή ατμόσφαιρα .Η λειτουργία του είναι ιδιαίτερα ήσυχη, with noise levels up to 37dB, offering hassle-free comfort. At the same time, the possibility of introducing fresh air up to 15% contributes to improving air quality, δημιουργώντας ένα πιο υγιεινό περιβάλλον για χρήστες και επισκέπτες .Ιδανική επιλογή με υπογραφή TCL.Η επιλογή ενός σύγχρονου συστήματος κασέτας εξασφαλίζει αποδοτικότητα και αξιοπιστία σε βάθος χρόνου. This particular model combines advanced technology, high performance and elegant design, being a complete air conditioning solution. Choosing TCL, invest in quality and functionality that meets the needs of every modern space. The cassette conditioner 12010 BTU by TCL offers a great user experience, making TCL a reliable choice for cooling and heating all year round.
| TCL model | TCD-12CHRH/DV |
| Nominal cooling efficiency |
|
|
| Rated heating efficiency |
|
|
| Phdesignc | W | 3.500 |
| SEER | W/W | 6,5 |
| Energy Class Cooling | A ++ |
| Phdesignh (Middle Zone) | W | 2.300 |
| SCOP(Middle Zone) | W/W | 4 |
| Heating energy class (Middle Zone) | A + |
| Average Annual Energy Consumption (KWh/a)Cooling | 189 |
| Heating (middle zone) | 775 |
| Operating temperature range | °C | 16-31 |
| Ambient temperature range |
|
|
|
| Air supply and Noise level |
| Indoor unit air supply | m3/h | 550 |
| Sound pressure level (S/H/M/L/Silent) | Indoor | dB(A) | 42/40/38/36/44/30/27 |
| Sound pressure level(Typical conditions) | External | dB(A) | 52 |
| TCL Electrics |
| Electrical supply/ Connection |
|
| Electrical supply side | External |
| Power Supply Voltage Range | (V) | 165~265 |
| Communication cable | 4×0.75mm2 |
| Power supply cable | Strands x Cross Section | 3×1.5mm2 |
| Maximum Current | A | 9 |
| Characteristics of TCL cooling network |
| Refrigerant type/quantity/GWP/CO2 equivalent | R32/0.53kg/675/0.358t |
| Pipe cross-section |
|
|
| Maximum length | m | 25 |
| Maximum altitude difference | m | 10 |
| Prefilling | m | 5 |
| Completion | gr/m | 15 |
| Dimensions of TCL units |
| Net dimensions (M x Y x B) | Indoor | mm | 570x245x570 |
| Net Weight |
|
|
|
| External | kg | 22 |
| Panel | kg | 2,7 |
