TCL CONSOLE TYPE AIR CONDITIONER 16050 BTU TCC-18ZHRH/DV
TCL CONSOLE TYPE AIR CONDITIONER 16050 BTU TCC-18ZHRH/DV
The consoles TCL TCC-ZHRH/DV they are an excellent air conditioning solution for those looking for high performance and absolute comfort
| BTU/H | |
|---|---|
| Manufacturers |
Description
TCL CONSOLE TYPE AIR CONDITIONER 16050 BTU TCC-18ZHRH/DV
| TCL model | TCC-18ZHRH/DV |
| Nominal cooling efficiency |
|
|
| Rated heating efficiency |
|
|
| Phdesignc | W | 5.000 |
| SEER | W/W | 6,1 |
| Energy Class Cooling | A ++ |
| Phdesignh (Middle Zone) | W | 3.900 |
| SCOP(Middle Zone) | W/W | 4 |
| Heating energy class (Middle Zone) | A + |
| phdesignh (hot zone) | W | 3900 |
| SCOP (hot zone) | W/W | 5,1 |
| Heating energy class(hot zone) | A +++ |
| Average Annual Energy Consumption (KWh/a)Cooling | 273 |
| Heating (middle zone) | 1152 |
| Operating temperature range | °C | 16-31 |
| Ambient temperature range |
|
|
|
| Air supply and TCL Noise level |
| Indoor unit air supply | m3/h | 750 |
| Sound pressure level (S/H/M/L/Silent) | Indoor | dB(A) | 46/43/40/38/36/32/28 |
| Sound power level(Typical conditions) | External | dB(A) | 55 |
| TCL Electrics |
| Electrical supply/ Connection |
|
| Electrical supply side | External |
| Power Supply Voltage Range | (V) | 165~265 |
| Communication cable | 4×0.75mm2 |
| Power supply cable | Strands x Cross Section | 3×1.5mm2 |
| Maximum Current | A | 12 |
| Characteristics of TCL cooling network |
| Refrigerant type/quantity/GWP/CO2 equivalent | R32/0.96kg/675/0.648t |
| Pipe cross-section |
|
|
| Maximum length | m | 25 |
| Maximum altitude difference | m | 15 |
| Prefilling | m | 5 |
| Completion | gr/m | 25 |
| Dimensions of TCL units |
| Net dimensions (M x Y x B) | Indoor
|
mm
|
700x600x215
|
| Net weight |
|
|
|
