TCL ΚΛΙΜΑΤΙΣΤΙΚΟ ΜΗΧΑΝΗΜΑ MIRACLE H-09CHSD/XA81I
TCL ΚΛΙΜΑΤΙΣΤΙΚΟ ΜΗΧΑΝΗΜΑ MIRACLE H-09CHSD/XA81I
| Manufacturers |
|---|
Description
TCL ΚΛΙΜΑΤΙΣΤΙΚΟ ΜΗΧΑΝΗΜΑ MIRACLE H-09CHSD/XA81I
| MODEL | MIRACLE H-09CHSD/XA81I |
| Nominal cooling efficiency |
|
|
| Nominal cooling efficiency |
|
|
| Design load (cooling) | w | 2.600 |
| Design load (heating, hot zone) | w | 2.300 |
| Nominal SEER (cooling) | w/w | 6,1 |
| Energy class (cooling) | A++ |
| Nominal SCOP (heating, middle zone) | w/w | 4 |
| Energy class (heating, middle zone) | A+ |
| Nominal SCOP (heating, hot zone) | w/w | 5,1 |
| Energy class (heating, hot zone) | A+++ |
| Annual energy consumption |
|
|
|
| Dehumidification | Liters/h | 1 |
| Sound power level (interior) (S/H/M/L/Mute) | dB(A) | 52/47/43/35/32 |
| Sound power level (abroad) | dB(A) | 62 |
| Sound pressure level (interior) (S/H/M/L/Mute) | dB(A) | 42/37/33/25/22 |
| Sound pressure level (abroad) | dB(A) | 52 |
| Electrical Data |
| Power supply | 220-240V~/50Hz/1P |
| Operating voltage range | V | 165~265 |
| Operating current |
|
|
|
| Power consumption |
|
|
|
| Cooling circuit |
| Refrigerant / Quantity / GWP / CO2 Equivalent | R32/0.49kg/675/0.331tonnes |
| Compressor | Type | Rotary |
| Air flow (cooling heating) | m3/h | 420/420 |
| Συνδέσεις TCL |
| Cooling piping |
|
|
| Electrical connection |
|
|
| Λοιπά TCL |
| Προπλήρωση | m | 5 |
| Συμπλήρωση | gr/m | 15 |
| Maximum length of cooling pipes | m | 25 |
| Μέγιστη υψομετρική διαφορά | m | 10 |
| Adjustable temperature range | °C | 16-31 |
| Ambient temperature operating range |
|
|
| Net dimensions (ΠxΥxΒ) |
|
|
| Net weight |
|
|
