NITTO AIR CONDITIONER 9000 BTU AKOII-09NO
air conditioner 9000 BTU ”AIKO-09EI” NITTO
With harmony of strength and aesthetics. This is Nitto Electric's new AIKO series. He came to create the ideal air conditioning conditions, meeting the needs of your own space, with sensitivity for the environment, low energy consumption and long-term reliability.
| BTU/H | |
|---|---|
| Manufacturers |
Description
NITTO AIR CONDITIONER 9000 BTU AKOII-09NO
NITTO ELECTRIC AIKOII air conditioners have a harmony of power and aesthetics. This is the new AIKOII NITTO ELECTRIC series . He came to create the ideal air conditioning conditions, meeting the needs of your own space, with sensitivity for the environment, low energy consumption and long-term reliability.
NITTO ELECTRIC AIR CONDITIONER AIKO
RAPID COOLING Ability to supply cold air from 25° to 18° in just 30”.
RAPID HEATING Ability to provide hot air from 20° to 40° in just 60”.
SMART AIR FLOW In cooling mode the air is directed towards the ceiling, while in heating towards the floor.
3-POWER FILTER The 3-POWER filter (Ascents / Catechin / Vitamin C) will provide the ideal atmosphere in your space.
MOLD PROTECTION After the unit is turned off, the fan will continue to run to dry the mechanism to prevent mold from forming, bacteria and unpleasant odors.
ECO FUNCTION By activating the Eco function, save energy in cooling and heating, maintaining a constant operating range.
SLEEP MODE In Sleep mode, your air conditioner will automatically adjust the temperature and fan speed so you can sleep more peacefully, more comfortable and more pleasant.
TURBO FUNCTION When you need extra power in the air flow, Turbo mode is there, with the press of a single key.
TIMER FUNCTION With the Timer function you can choose when the operation of your unit will be activated or deactivated.
SELF-DIAGNOSIS FUNCTION The air conditioner understands you and talks to you. When it detects a problem in its operation, it will guide you by displaying special messages on the panel's bright screen.
WIFI STANDARD Take control of the air conditioner in your hands, wherever you are through the NITTO ELECTRIC Smart Life app
SILENT MODE Through the control you can put the unit in silent mode “Mute”.
AIR ADJUSTMENT 5 SPEEDS You can choose one of 5 airflow speeds based on the needs of your space.
COLD CURRENT PROTECTION During heating mode the air conditioner will start to supply air with a short delay. This is done in order to achieve the adaptation of the air to the appropriate temperature and to avoid the feeling of discomfort from the presence of cold currents.
INDEPENDENT DEHUMIDIFICATION With the independent dehumidification function you can significantly reduce the humidity in your room.
SMART DEFROST With smart defrost the air conditioner will proceed to defrost when conditions require it and not based on regular programming.
AUTOMATIC RESTART The air conditioner remembers its operating mode. In the event of a power outage and when the power comes back on, the air conditioner will automatically start working in the same mode as before it stopped.
ENVIRONMENTAL REFRIGERANT R32 Refrigerant R32 is extremely environmentally friendly, achieving the highest levels of performance.
NITTO ELECTRIC
AIR CONDITIONER NITTO MACHINE 9000 BTU "AKO-09EI” NITTO
| Model NITTO ELECTRIC | AKOII -09EI | ||
| Nominal cooling efficiency | W | 2.600(940~3.300) | |
| Btu/h | 8.870(3.210-11.260) | ||
| Rated heating efficiency | W | 2.610(940~3.360) | |
| Btu/h | 8.910(3.210~11.460) | ||
| Design load (cooling) | W | 2,600 | |
| Design load (heating-warm zone) | W | 2,200 | |
| Nominal SEER (cooling) | W/W | 6.1 | |
| Energy class (cooling) | A++ | ||
| Nominal SCOP (heating, middle zone) | W/W | 4.0 | |
| Energy class (heating, middle zone) | A+ | ||
| Nominal SCOP (heating, hot zone) | W/W | 5.1 | |
| Energy class (heating, hot zone) | A+++ | ||
| Annual energy consumption | Cooling | kwh/a | 149 |
| Heating | kwh/a | 604 | |
| Dehumidification | Liters/h | 1.0 | |
| Sound power level (interior) (H/M/L/Mute) | dB(A) | 50/47/43/35/32 | |
| Sound power level (abroad) | dB(A) | 60 | |
| Sound pressure level (interior) (H/M/L/Mute) | dB(A) | 40/37/33/25/22 | |
| Sound pressure level (abroad) | dB(A) | 50 | |
| Electrical Data | |||
| Power supply | 220-240V~/50Hz/1P | ||
| Operating voltage range | V | 165~265 | |
| Operating current | Cooling | A | 4.0(1.2~8.0) |
| Heating | A | 3.8(1.2~9.0) | |
| Power consumption | Cooling | W | 825(240～1.380) |
| Heating | W | 767(240～1.552) | |
| Cooling circuit | |||
| Refrigerant / Quantity / GWP / CO2 Equivalent | R32/0.45kg/675/0.304tonnes | ||
| Compressor | Type | Rotary | |
| Air flow (cooling heating) | m3/h | 420/420 | |
| Connections | |||
| Cooling piping | Gas | Inches | 3/8″ |
| Liquid | Inches | 1/4″ | |
| Electrical connection | Power supply cable | 3*1,5mm²/ext. unit | |
| Communication cable | 4*1,5mm² | ||
| Electr. Security (A) | 10 | ||
| So | |||
| Maximum length of cooling pipes | m | 25 | |
| Maximum altitude difference | m | 10 | |
| Adjustable temperature range | ℃ | 16-31 | |
| Ambient temperature operating range | External | ℃ | Cooling:15~53/ Heating:-20~30 |
| Indoor | ℃ | Cooling:17~32/ Heating:0~30 | |
| Net dimensions (Π x Υ x B) | Indoor | mm | 698×255×190 |
| External | mm | 712×459×276 | |
| Net weight | Indoor | kg | 6.5 |
| External | kg | 22 | |
